Pensky-Martens Flash Point (Closed) Apparatus

The Pensky-Martens Closed Cup Apparatus is used to determine the flash point of bitumen, fuel oils, and other petroleum products having a flash point above 49 C using a closed-cup method that provides more accurate and reproducible results for such products compared to open-cup methods. The sample is heated in a closed test cup fitted with a stirrer, and a test flame is introduced periodically through a shutter mechanism at specified temperature intervals to detect the flash point.

It has a brass coil cup fitted with a heat resistance handle. The cup is provided with a lid which includes stirring device, a cover, shutter and a flame explosive device. The shutter is operated by a spring handle. A flexible shaft is provided in the hand operated stirrer. A Cast Iron stove is fitted with a metal top plate mounted on an upright member (Gas Manifold) and it feeds a needle valve con-trolled burner.

Thermometer IP 15C Range: 5°C to +110°C

Thermometer IP 16C Range: 90°C to +370°C

Electrical heating, with gas test jet and electric heater with energy regulator. Suitable for operation on 220 V, 50 Hz, Single Phase, AC Supply.
